The S6 600W wind turbine is a compact horizontal-axis renewable-energy generator supplied as a single unit. Choose the required 12V, 24V, or 48V version when placing the order.
Key Features
- 6-blade configuration
- Compact horizontal-axis design
- Three-phase rare-earth permanent-magnet AC generator
- Overspeed three-phase short-circuit braking system
Technical Specifications
- Rated power: 600W
- Maximum power: 630W
- Rated voltage options: 12V / 24V / 48V
- Starting wind speed: 3 m/s
- Rated wind speed: 13 m/s
- Safe wind speed: 55 m/s
- Wind wheel diameter: 1.2 m
- Number of blades: 6
- Blade material: nylon composite fiber
- Net turbine weight: 8.6 kg
Package Contents
- Wind turbine generator
- Controller
- Screws and nuts
- Installation tools
- Mounting flange
- Tower, inverter, and battery are not included
Packaging & Shipping Data
- Carton packaging
- Carton dimensions: 75 × 28 × 25 cm
- Carton volume: 0.0525 CBM per unit
Ordering Information
- Stock: 5,000 units
- Minimum order: 1 unit
- Quantity step: 1 unit
- Specify the required voltage in the order notes
